Product Parameter
|
Product Name |
Injector assembly |
|
Model Number |
612630090012 |
|
Application |
HOWO 70 Mining; howo a7 |
|
Material |
Standard Material, Original |
Product Feature
1).Famous brand, Easy to install.
2).High quality materials to extend the service life of hart parts
Production details
|
Price |
Negotiable |
|
Payment term |
TT, LC |
|
Delivery date |
Negotiable |
|
Packing |
export standard |
|
Market |
Middle East/ Africa/Asia/South America/Europe/North America |
|
Warranty |
1 year |
|
MOQ |
1 set |
Our Advantages
1). Fast installation
2). Smooth operating
3). Strict quality management systemes
4). Prompt delivery
5). High quality products
Our Services
1).Provide the technical design and solutions;
2).New plant construction guidance;
3).Designing and manufacturing of non-standard equipment;
4).Professional technical training and guidance on site according to the contract;
5).Supply accessories at any time;
6).Tele-technical consulting and services;
7).Other special technical service according to client's requirements.
Quality Assurance
1). Checking raw material before producing.
2). Checking one by one before the assembling
3). Checking one by one during the production
4). Have 100% inspection before the delivery.
Our history
1).2010 Zhongyi machinery Co.,Ltd. Founded, with main products of spare parts for concrete pumps and concrete mixer trucks.
2).2011 Zhongyi machinery started to cooperate with ACM located in Italy, our products entered EU market.
3).2016 start cooperating with TRI who is famous distributor in middle East countries, we provide the all kind of parts. And meanwhile we started cooperated with Zoomlion customer in South east Asia.
4).2019 we purchased one factory for manufacture the casting products, and began to cooperate with the biggest pump part distributor in UAE.
5).2023 our company has passed the ISO quality system registration, and has obtained ISO 9001:2008 certificate.
6).2024 our set up our oversea branches in Oman Muscat.
Our factory and warehouses
Our Exhibitions
FAQ
Q: Which vehicle and engine models is this injector assembly (Part No. 612630090012) compatible with?
A: This fuel injector is primarily designed for SINOTRUK series heavy-duty commercial vehicles equipped with Weichai high-pressure common rail diesel engines, including SINOTRUK HOWO 6X4/8X4 series heavy-duty tractors and dump trucks, SINOTRUK HOWO T7H/TH7 series high-end long-haul commercial vehicles, SINOTRUK Sitrak G7/G7H series heavy-duty trucks, and SINOTRUK special modified vehicles such as mixer trucks, crane trucks and mining transport vehicles.
Q: What are the key technical specifications of this injector assembly?
A: The key specifications include: Part Number 612630090012; Product Type Heavy-Duty Commercial Vehicle Diesel Engine High-Pressure Common Rail Fuel Injector; Nozzle Material Tungsten Carbide Hard Alloy; Injector Body Material High-Strength Aluminum Alloy; Nozzle Hole Number 6 holes; Injection Angle 155°; Working Pressure ≥160 MPa; Overall Dimensions 180mm×35mm×35mm; Net Weight 0.6 kg; Quality Standard ISO90007 and CCC Certification with 100% factory inspection qualified.
Q: What is the main function and working principle of this injector assembly?
A: The injector is installed on the engine cylinder head and connected to the fuel rail, undertaking two critical functions: precision fuel atomization and injection, and combustion efficiency optimization. It receives control signals from the engine ECU, accurately regulating fuel injection timing, injection quantity and injection pressure according to different working conditions. It atomizes diesel fuel into fine droplets and sprays them into the combustion chamber, ensuring full mixing with air to achieve efficient and complete combustion, which directly improves the engine's power output, fuel economy and emission compliance.
Q: What are the ordering details, packaging methods and warranty terms for this product?
A: The minimum order quantity is 1 piece, with a delivery time of 3–7 days. It supports payment methods including T/T and West Union. The packaging method uses protective film wrapping plus shock-absorbing foam plus carton plus wooden case, with customized packaging available for bulk orders.
