Product Parameter
|
Product Model |
WG9700610034 / WG9700610034/3 |
|
Size Specification |
22.5 × 9.00 |
|
Applicable Tire Type |
Tubeless / Tube Type |
|
Center Bore (CB) |
Φ281 mm |
|
Pitch Circle Diameter (PCD) |
335 mm |
|
Bolt Holes |
10 Holes |
|
Wheel Offset (ET) |
Inset 164 mm |
|
Plate Thickness |
11 mm |
|
Unit Weight |
Approx. 34 kg - 42 kg |
|
Maximum Load |
12,000 kg/wheel |
Product Feature
1). High strength and load capacity:
• In the process of vehicle driving, the steel plate support needs to withstand various stresses and impact forces brought by the body, goods and road bumps. Aolong steel plate bearing is made of high-quality steel, after strict process and quality control, with high strength, can effectively support the weight of the vehicle, to ensure that in the case of heavy load is not easy to deformation or damage, to ensure the normal operation and safety of the vehicle.
• For some large engineering vehicles or heavy transport vehicles, this high-load-bearing steel plate support is an important part to ensure vehicle performance and safety.
2). Good wear resistance and durability.
3). Accurate size and good installation adaptability
Production details
|
Price |
Negotiable |
|
Payment term |
TT, LC |
|
Delivery date |
Negotiable |
|
Packing |
export standard |
|
Market |
Middle East/ Africa/Asia/South America/Europe/North America |
|
Warranty |
1 year |
|
MOQ |
1 set |
Our Advantages
1). Fast installation
2). Smooth operating
3). Strict quality management systemes
4). Prompt delivery
5). High quality products
Our Services
1).Provide the technical design and solutions;
2).New plant construction guidance;
3).Designing and manufacturing of non-standard equipment;
4).Professional technical training and guidance on site according to the contract;
5).Supply accessories at any time;
6).Tele-technical consulting and services;
7).Other special technical service according to client's requirements.
Quality Assurance
1). Checking raw material before producing.
2). Checking one by one before the assembling
3). Checking one by one during the production
4). Have 100% inspection before the delivery.
Our history
1).2010 Zhongyi machinery Co.,Ltd. Founded, with main products of spare parts for concrete pumps and concrete mixer trucks.
2).2011 Zhongyi machinery started to cooperate with ACM located in Italy, our products entered EU market.
3).2016 start cooperating with TRI who is famous distributor in middle East countries, we provide the all kind of parts. And meanwhile we started cooperated with Zoomlion customer in South east Asia.
4).2019 we purchased one factory for manufacture the casting products, and began to cooperate with the biggest pump part distributor in UAE.
5).2023 our company has passed the ISO quality system registration, and has obtained ISO 9001:2008 certificate.
6).2024 our set up our oversea branches in Oman Muscat.
Our factory and warehouses
Our Exhibitions
FAQ
Q1: Why is the unit weight listed as a range from 34kg to 42kg? What is the difference?
A1: This part number (WG9700610034) covers two different production versions.
Standard Version:Weighs approx. 41-42kg, made of standard steel, suitable for heavy-duty transport and construction trucks.
Lightweight II Generation:Weighs approx. 34-36kg, made of high-strength lightweight steel to reduce fuel consumption, suitable for standard-load logistics transport. Please inform us of your specific needs before ordering.
Q2: The center bore of my old rim is 220mm, but your data shows 281mm. Will it fit?
A2: Please pay close attention! WG9700610034 does indeed have two bore configurations:
If you are using a HOWO A7/T7H standard highway axle, it usually requires Φ281mm.
If you are using a specific construction axle or older model, it may require Φ220mm.
Due to varying axle configurations, the part number alone cannot guarantee a 100% match. To avoid return shipping costs, we strongly recommend measuring the center bore of your old rim before placing an order.
Q3: Can this rim handle mining road conditions? Is it prone to cracking?
A3: Absolutely. The WG9700610034 is manufactured from high-quality Q235 carbon structural steel using a hot rolling and integral stamping process, rather than ordinary welding. This process ensures superior impact resistance at the flange. Combined with the 11mm thick plate, it is designed to withstand severe vibrations on mining roads or potholed surfaces without deforming or cracking.
Q4: Is this a genuine original part or an aftermarket part? Is the quality guaranteed?
A4: We offer two options:
Original OEM: Comes with Sinotruk laser anti-counterfeit labels. Higher price, most stable quality.
Premium Aftermarket: Produced by designated suppliers of Sinotruk, adhering to the same national (GB) quality standards. Offers high cost-effectiveness with the same warranty policy as the original.
If you seek the best value, we recommend the premium aftermarket version. If brand authenticity is strictly required, please specify that you need the Original OEM version.
